Deck Concept

[Devin Catron]

Heres a deck that I came up with. Me and Kodye mat or may not be making it but the fender thats on it we may make. Its a 4.5" deck with 1/4" concave and a 85 degree headtube and yes its all the exact size and angles in the drawing. Its all going to be constructed out of triangular tubing which is way stronger than round and square for anyone who didnt know. I did it at home so I couldnt make the model on Autocad or Solidworks so I had to use Sketchup but you get the idea. and yes i do realize there are no holes for the back wheel.



[parrish]

headtube is a little big there buddy :b



[Jacobo]

looks solid
cnc'd headtube?
+ u shud add som stock speed holes in the center of the deck (on top)



[parrish]

NO DO NOT DO ThAT



[Devin Catron]

i dont know what you mean by "speed holes" if that means drilling holes in the deck than no that only weakens it. and the diameter of the headtube it a bit big but thats an easy fix. and i want to design a pair of unique bars so if anyone has any ideas just PM them to me



[Noah Fraley]

if u make bars go hic



[j-DoGg]

is micheal knudson going to be welding this?



[Devin Catron]

no. kodyes dad welds and hes really good at it so he mat help. but if he doesnt than i think michael will help id he gets one
